Wide Model Coverage
Indoor and outdoor models cover short-distance commercial displays through large-format outdoor signage.
Fixed Installation
Standard LED Display Module
Indoor P1.25–P5 · Outdoor P2.5–P10
Standardized LED modules for commercial signage, information displays and fixed projects.
GZX standard LED modules cover fine-pitch indoor displays and high-brightness outdoor installations. Multiple module formats, LED packages and scan configurations make it possible to match viewing distance, cabinet structure and maintenance access.
- Supply format
- Complete system or product units
- MOQ
- Confirmed by configuration
- Customization
- OEM / project configuration
- Lead time
- Confirmed after specifications
Share your screen size, application and installation country for an accurate quote.
01 / PRODUCT OVERVIEW
Designed Around Real Project Work.
Product configuration is matched to the viewing environment, screen dimensions, installation method and control requirements.
- P1.25–P10
- Available Pitch Range
- 4500 cd/m²
- Outdoor Brightness
- 3840 Hz
- Maximum Refresh Rate
- 3 sizes
- Main Module Formats
Standardized Formats
Common module sizes simplify cabinet planning, replacement and long-term maintenance.
Outdoor Visibility
Selected outdoor modules reach up to 4500 cd/m² for high-ambient-light installations.
System-Level Matching
Power supplies, receiving cards, control processors and spares can be configured around the final screen.
02 / KEY SPECIFICATIONS
Confirm the Model Before Ordering.
Values shown cover the available series. The final quotation and production specification will identify the exact model and configuration.
Compare Full Product Range| Indoor pixel pitch | P1.25–P5 |
|---|---|
| Outdoor pixel pitch | P2.5 / P3 / P3.076 / P4 / P5 / P6 / P6.67 / P8 / P10 |
| Module formats | 320 × 160 mm / 256 × 128 mm / 192 × 192 mm |
| Outdoor brightness | 4300–4500 cd/m², depending on model |
| Refresh rate | 1920 / 3840 Hz |
| LED package | 1415 / 1921 / 2525 / 3535, depending on model |
| Scan mode | 1/16 to 1/4, depending on model |
| Maintenance | Matched to front- or rear-service cabinet design |
| Control system | Configured to final resolution and project requirements |
03 / APPLICATIONS
Where This Product Fits.
- 01Retail signage
- 02Control rooms
- 03Transport information
- 04Building façades
- 05Sports venues
- 06Public information displays
04 / CUSTOMIZATION & DELIVERY
One Product, Configured for Your Project.
Send the project basics first. We will use them to confirm the product, system list and commercial quotation.
- 01Share Requirements
Application, screen size, viewing distance, country and target date.
- 02Confirm Solution
Product model, structure, control system and supporting equipment.
- 03Approve Quotation
Final specifications, quantities, packaging and delivery terms.
- 04Production & Test
Production, system testing and shipment preparation follow the confirmed order.
05 / BUYER FAQ
Questions Before You Order.
Need a project-specific answer? Send your drawing, target size or existing module photos.
Do you supply modules only or a complete screen?
Both are available. For a complete screen, provide the target size, installation environment and viewing distance so the cabinet, control and power systems can be matched.
How do I confirm module compatibility for replacement?
Share the existing module size, resolution, scan mode, connector layout, driver IC information and clear front-and-rear photos. Compatibility must be confirmed before ordering.
What affects outdoor brightness selection?
Screen direction, local sunlight, operating hours and content type all matter. The quoted module should be matched to the real installation rather than brightness alone.
START YOUR INQUIRY
Get a Configuration-Based Quote.
Tell us where the screen will be used, the target dimensions and the required delivery date. We will match the model and supporting system.
PROJECT INQUIRY
Start with Your Requirements.
Choose a product and tell us about your installation. We will help confirm the model and configuration.
Your details open as a draft in WhatsApp or your email app. Review and send there to contact GZX.
